REGION ap-south-3 · TIER-IV NOIDA (YOTTA NM1 & CTRLS)

Sovereign VirtualPrivate Cloud.Zero EgressPenalties.

Hardware-isolated multi-tenant L2/L3 networking running across dual Intel Xeon Platinum 8168 & AMD EPYC bare-metal hypervisors in Noida. Tenant bandwidth is 1 Gbps shared. Build zero-trust private interconnects, subnets, custom routing, and site-to-site cryptographic tunnels without unmetered transit taxes.

ACTIVE L3 ORCHESTRATIONSYNCHRONIZED
Encapsulation
Geneve overlay
DPDP Boundary
100% Domestic
Default MTU
1500 MTU (9000 jumbo frames planned)
Intra-VPC Egress
₹0.00 / Free
BGP AS216298CHACHA20-POLY1305 ENCRYPTION
>datadack vpc create --region noida --cidr 10.100.0.0/16 --mtu 1500
Transit latency
< 0.38ms
p99 inter-rack
Packet frames
1500MTU
9000 jumbo frames planned, not yet available
Cross-subnet egress
₹0.00/mo
Zero intra-region transfer fees
Tenant bandwidth
1Gbps shared
Shared across the tenant, not dedicated
Physical Containment & Security Engineering

Kernel-Level Virtualization.Enforced Isolation.

Why conventional multi-tenant hyperscaler networks fail national sovereignty, and how DataDack re-engineers isolation at the Linux kernel vSwitch with Geneve VNIs and eBPF filtering.

DPDP Act 2023 & In-Country Residency

100% of network frames and control-plane telemetry are physically confined to Noida Tier-IV data halls. Zero exposure to the US CLOUD Act or foreign extraterritorial discovery subpoenas.

MeitY Empaneled Standards

Geneve VNI Segmentation

Tenant packet isolation enforced by per-VPC Geneve VNIs and eBPF kernel filters, preventing hypervisor side-channel exploitation and shared noisy-neighbor bridge saturation.

Per-VPC VNI Isolation

Statutory Flat-Rate Economics

Replaces AWS's $0.056/GB NAT processing tax and $0.01/GB cross-AZ tax with a flat ₹1,650/mo NAT gateway and ₹0.00 intra-region data transfer across all your subnets.

~52% Lower Base Than AWS
Topological Visualizer

3-Tier Enterprise VPC Topology& Formal Reachability

INSPECTOR ACTIVE:vpc-del1-prod (10.100.0.0/16)
01 / VPC boundary · 10.100.0.0/1602 / Public DMZ subnet · 10.100.1.0/2403 / Private app and air-gapped DB subnets04 / Gateways attach to the route table05 / Traffic flows along the enforced paths
INTERNET
igw-sovereign-01
VPC CONTAINER: 10.100.0.0/16
MTU: 1500/OVERLAY: GENEVE/wg-gateway-01 · 192.168.99.0/24FLOWS: ISOLATED
PUBLIC DMZ SUB-0110.100.1.0/24
Internet & Edge Transit
Managed NAT GW₹1,650/mo
WireGuard Gateway₹0 License
nat-del1-primary
PRIVATE APP SUB-0210.100.2.0/24
Internal Microservices
app-node-cluster-01<0.12ms to DB
Kubernetes CNIeBPF Native
AIR-GAPPED DB SUB-0310.100.3.0/24
Cryptographic Vault
PostgreSQL 5432DPDP Certified
NVMe Cluster Sync1500 MTU
Route table

Every path,formally enforced.

VPC Route Table Entries [rtb-sovereign-core-01]
4 ENFORCED RULES · VERIFIED
Destination CIDRTarget / Next-HopScope TierStatusTraversal Cost
10.100.0.0/16local (Kernel vSwitch)All SubnetsActive (0.1ms)₹0.00 / Free
0.0.0.0/0 (Public DMZ)igw-sovereign-0110.100.1.0/24 (DMZ)ActiveStandard Transit
0.0.0.0/0 (Private Apps)nat-del1-primary10.100.2.0/24 (App Tier)Active (0.35ms)₹0.00 Data Tax
192.168.99.0/24 (Corp Mesh)wg-gateway-01Site-to-Site TunnelActive (Kernel Crypto)₹0.00 / Tunnel
Primitives Specification

Core VPC CapabilitiesBuilt on Sovereign Silicon

Every DataDack VPC is backed by Geneve segmentation and eBPF filtering in the hypervisor kernel.

RFC 1918 COMPATIBLE

Isolated VPC Networks

Full control of private address allocations across 10.0.0.0/8, 172.16.0.0/12, and 192.168.0.0/16 ranges with secondary CIDR attaching.

Subnet Masks: /16 to /28 prefixes
HIERARCHICAL SEGREGATION

Tiered Subnet Meshes

Carve isolated public DMZs, private application clusters, and air-gapped database zones with deterministic local switching and zero hairpin penalties.

Tenant Bandwidth: 1 Gbps shared
KERNEL MICRO-SEGMENTATION

Stateful Security Groups

Packet filtering executed in hypervisor eBPF prior to guest VM execution. Ingress and egress state tracking with zero packet overhead.

Filter Overhead: < 5 microseconds
NEXT-HOP CONTROL

Custom Route Tables

Direct traffic down designated egress paths via Internet Gateways, Managed NAT, VPC Peering Routers, or custom WireGuard cryptographic appliances.

Routing Table Capacity: 100 entries / table
ZERO SYNTHETIC TRAFFIC

Reachability Analyzer

Automated formal verification engine that validates mathematical packet paths across your route tables and firewalls without injecting traffic.

Formal Engine: SAT Solver Graph Verifier
VIRTIO INTERFACES

Elastic Network Interfaces (ENIs)

Hot-plug virtual network adapters into instances on the fly. Enable dual-homed appliances, dedicated management NICs, and high-availability failover scripts.

Adapter Limit: Up to 8 ENIs per VM
Zero-Trust Hybrid Interconnect · Free Software

High-Performance SovereignWireGuard & OpenVPN Tunnels

Connect remote engineering teams, office datacenters, or on-premise hardware directly into your VPC subnets. Software and licensing are 100% FREE — pay only base hardware compute.

Pay base compute only: from ₹250/mo

WireGuard Kernel Appliance

100% Free Software Included
₹0 license

Lightweight, state-of-the-art cryptography built directly into the Linux kernel. Eliminates handshake latency with ChaCha20-Poly1305 ciphers.

  • Instant QR-code onboarding for engineers via Console
  • Automated ChaCha20-Poly1305 key generation & rotation
  • Native binding to any VPC subnet CIDR range
  • Zero per-user licensing costs or connection limits
Protocol: UDP/51820Deploy WireGuard Tunnel →

OpenVPN Enterprise Gateway

100% Free Software Included
₹0 license

Engineered for organizations bound by enterprise compliance standards requiring strict TLS certificates, SAML 2.0 integration, and hardware token Multi-Factor Authentication.

  • Full TOTP / Google Authenticator / Duo MFA enforcement
  • SAML 2.0 / Okta / Azure AD identity directory sync
  • TCP 443 fallback for restricted corporate firewall bypass
  • Centralized access log streams with IP attribution audit
Protocol: TLS 1.3 / TCP-UDPDeploy OpenVPN Gateway →
Unmetered Transparency

Pricing Matrix vsAWS Mumbai (ap-south-1)

Hyperscalers monetize networking through convoluted egress penalties, data-processing taxes, and complex routing tariffs. DataDack provides predictable flat infrastructure economics.

Network Primitive / ComponentDataDack Sovereign VPCAWS Mumbai (ap-south-1)Structural Savings
Static / Elastic IPv4 Address
Dedicated Indian APNIC routed IP
₹250 / mo flat
No idle or unattached penalties
$0.005/hr ≈ ₹305 / mo
+ $0.005/hr idle unattached penalty
Save ~18% + No Idle Tax
Managed NAT Gateway
Outbound private subnet internet translation
₹1,650 / mo flat
₹0.00 Data Processing Surcharge
$0.056/hr ≈ ₹3,413 / mo
+ $0.056/GB data processing tax
~52% Lower Base + Zero Data Tax
Zero-Trust VPN (WireGuard / OpenVPN)
Site-to-site & remote engineer gateway
FREE Software (₹0 License)
Pay base compute (from ₹250/mo)
AWS Client VPN
$0.05/hr conn + $0.05/hr endpoint
100% Free Software
VPC Peering Interconnect
Direct cross-VPC routing
₹0.00 / Free
Unmetered intra-region routing
$0.01 / GB
Billed each direction on transfer
100% Free Unmetered
Edge DDoS Protection
Inline SYN-flood & UDP reflection filter
₹0.00 / Included Standard
Always-on, no add-on subscription
AWS Shield Advanced
$3,000 / mo base subscription
Zero Cost Add-on
Cross-Subnet Data Transfer
Replication & database sync
₹0.00 / Free Unmetered
1500 MTU (9000 jumbo frames planned), 1 Gbps shared
$0.01 / GB
Cross-AZ egress penalty
Zero Metered Trap
Instances inside your VPC start at Starter 4 — ₹1,152/mo.vs AWS t3a.medium (₹2,210/mo) · ~48% lower

* AWS Mumbai (ap-south-1) pricing based on official published rates for NAT Gateway & data processing fees + IPv4 address charges at 1 USD = 83.5 INR equivalent, 730 hours/month.

Infrastructure as Code

Automate VPC Provisioningin Seconds

Declarative HCL snippets, zero-friction CLI commands, and REST APIs for automated GitOps workflows.

# Terraform HCL snippet for DataDack Sovereign VPC
resource "datadack_vpc" "prod" {
  name        = "vpc-noida-production"
  cidr_block  = "10.100.0.0/16"
  region      = "ap-south-3" # Noida Tier-IV Facility
  mtu         = 1500
  description = "Production sovereign network perimeter"
}

resource "datadack_subnet" "public_dmz" {
  vpc_id            = datadack_vpc.prod.id
  name              = "public-dmz-01"
  cidr_block        = "10.100.1.0/24"
  type              = "public"
  enable_nat        = true
}

resource "datadack_subnet" "private_app" {
  vpc_id            = datadack_vpc.prod.id
  name              = "private-app-02"
  cidr_block        = "10.100.2.0/24"
  type              = "private"
  nat_gateway_id    = datadack_subnet.public_dmz.nat_gateway_id
}

resource "datadack_security_group" "app_sg" {
  vpc_id      = datadack_vpc.prod.id
  name        = "sg-app-internal-only"
  description = "Allow inbound HTTP/gRPC only from Public DMZ"
  ingress {
    protocol    = "tcp"
    ports       = ["8000", "8080"]
    cidr_blocks = ["10.100.1.0/24"]
  }
}
# Deploy complete 3-tier VPC via DataDack CLI v2
datadack vpc create \
  --name "vpc-noida-production" \
  --region ap-south-3 \
  --cidr 10.100.0.0/16 \
  --mtu 1500

datadack subnet create \
  --vpc-name "vpc-noida-production" \
  --name "public-dmz-01" \
  --cidr 10.100.1.0/24 \
  --enable-nat

datadack subnet create \
  --vpc-name "vpc-noida-production" \
  --name "private-app-02" \
  --cidr 10.100.2.0/24 \
  --route-table-target nat-del1-primary
# Create VPC via Sovereign Control Plane REST API
curl -X POST https://api.datadack.cloud/v1/vpcs \
  -H "Authorization: Bearer $DATADACK_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "vpc-noida-production",
    "region": "ap-south-3",
    "cidr": "10.100.0.0/16",
    "mtu": 1500,
    "sovereignty_lock": true
  }'
High Availability & National Sovereignty

99.99% Network Uptime SLA &Direct Tier-IV NOC Escalation

Our software-defined fabric uses automated BGP failover, with tenant bandwidth of 1 Gbps shared. Fully compliant with the Digital Personal Data Protection (DPDP) Act 2023, data residency never leaves sovereign Indian territory.

99.99%
Financially backed SLA
MeitY
Empaneled standards
< 15 min
NOC WhatsApp escalation
24x7 Direct WhatsApp Desk
+91 87080 45050 (Direct L3 Network Leads)
Open WhatsApp Desk
PRIMARY CORE NODE:DEL-1 (NOIDA TIER-IV)
Campus:
Yotta NM1 & CtrlS DC2
NIXI Interconnect:
Delhi Exchange
Jurisdiction:
100% Indian Territory
Tenant Isolation:
Geneve VNI + eBPF

All routing control-planes and telemetry stay inside sovereign data halls with continuous audit trails.

Get started

Deploy on sovereign Indian cloud in minutes.

No sales call, no lock-in. Start with ₹1,000 in free credit on signup and benchmark your enterprise VPC workloads on sovereign Indian infrastructure.
